Two-phase displacement in 2D porous media

What is it about?

While experimental designs developed in recent decades have contributed to research on dynamic nonequilibrium effects in transient two-phase flow in porous media, this problem has been seldom investigated using direct numerical simulation (DNS). Only a few studies have sought to numerically solve Navier–Stokes equations with level-set (LS) or volume-of-fluid (VoF) methods, each of which has constraints in terms of meniscus dynamics for various flow velocities in the control volume (CV) domain. The Shan–Chen multiphase multicomponent lattice Boltzmann method (SC-LBM) has a fundamental mechanism to separate immiscible fluid phases in the density domain without these limitations. Therefore, this study applied it to explore two-phase displacement in a single representative elementary volume (REV) of two-dimensional (2D) porous media. As a continuation of a previous investigation into one-step inflow/outflow in 2D porous media, this work seeks to identify dynamic nonequilibrium effects on capillary pressure–saturation relationship (Pc-S) for quasi-steady-state flow and multistep inflow/outflow under various pressure boundary conditions. The simulation outcomes show that Pc, S and specific interfacial area (anw) had multistep-wise dynamic effects corresponding to the multistep-wise pressure boundary conditions. With finer adjustments to the increase in pressure over more steps, dynamic nonequilibrium effects were significantly alleviated and even finally disappeared to achieve quasi-steady-state inflow/outflow conditions. Furthermore, triangular wave-formed pressure boundary conditions were applied in different periods to investigate dynamic nonequilibrium effects for hysteretical Pc-S. The results showed overshoot and undershoot of Pc to S in loops of the nonequilibrium hysteresis. In addition, the flow regimes of multistep-wise dynamic effects were analyzed in terms of Reynolds and capillary numbers (Re and Ca). The analysis of REV-scale flow regimes showed higher Re (1<Re<10) for more significant dynamic nonequilibrium effects. This indicates that inertia is critical for transient two-phase flow in porous media under dynamic nonequilibrium conditions.

Featured Image

Photo by Artur Rutkowski on Unsplash

Photo by Artur Rutkowski on Unsplash

Why is it important?

While experimental designs developed in recent decades have contributed to research on dynamic nonequilibrium effects in transient two-phase flow in porous media, this problem has been seldom investigated using direct numerical simulation (DNS). Only a few studies have sought to numerically solve Navier–Stokes equations with level-set (LS) or volume-of-fluid (VoF) methods, each of which has constraints in terms of meniscus dynamics for various flow velocities in the control volume (CV) domain. The Shan–Chen multiphase multicomponent lattice Boltzmann method (SC-LBM) has a fundamental mechanism to separate immiscible fluid phases in the density domain without these limitations. Therefore, this study applied it to explore two-phase displacement in a single representative elementary volume (REV) of two-dimensional (2D) porous media. As a continuation of a previous investigation into one-step inflow/outflow in 2D porous media, this work seeks to identify dynamic nonequilibrium effects on capillary pressure–saturation relationship (Pc-S) for quasi-steady-state flow and multistep inflow/outflow under various pressure boundary conditions.

Perspectives
